0.214 - 0.437 Inch Grip 3/16 Inch Diameter X 0.572 Inch 5052 Aluminum Standard Flange Dome Head Blind Rivet
Item K39.316.067
The RivetKing In-Lock is a structural rivet with an internal locking feature. the locking feature is not visible when the rivet is applied. the mandrel is retained within the shear plane yielding high strength under shear loads and the internal lock insures positive mandrel retention which results in high strength under pullout loads. Typically used in the manufacturing or repair of truck bodies the In-Lock is leak resistant and has excellent clamp-up force. the In-Lock has a wide grip range and is offered in two diameters and two lengths. the mandrel breaks flush with the head when applied and is set without a special nose piece.
Delivering to
Estimated delivery: 3–7 business days
Order by 2pm CT
Couldn't load pickup availability
-
Free Shipping for All Orders Above $15
Receive free standard ground shipping on single orders totaling $15 or more, after discounts are applied and before taxes.
This offer is only valid in the continental United States.
Excludes expedited shipping methods and orders shipped outside the continental U.S.
-
Quality Assurance Guarantee
OneSource warrants that products delivered by OneSource to customers will be free from defects in material or workmanship under normal use for a period of thirty (30) days from the date of delivery.
It is the responsibility of the customer to return defective products within the warranty period. If OneSource determines that the products returned for warranty refund are not defective within the terms of the warranty, the purchaser shall be responsible for all handling and transportation costs.
If an item is returned as defective and it is determined that the product is not, a restocking fee may be charged.
Refunds will be issued in the form of an account credit or back to the original payment method.
-
Expert Customer Support
Our experts can help. Our experienced sales and support professionals are dedicated to helping you find the right parts for your projects.
Photographs are representational and may not be size accurate.
Description
Description
The RivetKing In-Lock is a structural rivet with an internal locking feature. the locking feature is not visible when the rivet is applied. the mandrel is retained within the shear plane yielding high strength under shear loads and the internal lock insures positive mandrel retention which results in high strength under pullout loads. Typically used in the manufacturing or repair of truck bodies the In-Lock is leak resistant and has excellent clamp-up force. the In-Lock has a wide grip range and is offered in two diameters and two lengths. the mandrel breaks flush with the head when applied and is set without a special nose piece.
- Weather-tight
- Designed by the makers of monobolts to use in place of monobolts without the use of special installation nosepieces
- Grip Range: 0.214 - 0.437 Inch
- Head Size: 0.385 Inch Dia x 0.085 Inch Height
- Head Style: Standard Flange Dome
- Hole Diameter: 0.191 - 0.201 Inch (#10)
- Item: Blind Rivet
- Length: 0.572 Inch
- Mandrel Material: Aluminum
- Mandrel Size: 0.118 Inch Dia
- Material: 5052 Aluminum
- Shear Strength: 550 lb
- Tensile Strength : 450 lb
- Type: Interlock Monobolt Structural
Specifications
General
- Type
- Interlock Monobolt Structural
- Material
- 5052 Aluminum
- Mandrel Material
- Aluminum
Dimensions
- Diameter
- 3/16 inch
- Length
- 0.572 Inch
- Hole Diameter
- 0.191 – 0.201 Inch (#10)
- Head Size
- 0.385 Inch Dia x 0.085 Inch Height
- Grip Range
- 0.214 – 0.437 Inch
- Mandrel Size
- 0.118 Inch Dia
Features
- Head Style
- Standard Flange Dome
- Tensile Strength
- 450 lb
- Shear Strength
- 550 lb
