Description
Description
Flange bolts are designed with a ridge below the bolt head. the circular flange under the head is made to hold the same power as a washer.
Specifications
General
- Measurement System
- Inch
- Type
- Partial Threaded
- Material
- Medium Carbon Steel
- Origin
- Imported
Dimensions
- Length
- 1 Inch
- Thread Type
- Coarse
- Diameter
- 1/4 Inch
- Threads Per Inch
- 20
- Thread Length
- 3/4 Inch
- Head Height
- 0.280 Inch
- Width Across Corner
- 0.409 – 0.433 Inch
- Body Diameter
- 0.245 – 0.250 Inch
- Hex Height
- 0.170 Inch
- Flange Diameter
- 0.560 Inch
- Flange Thickness
- 0.040 Inch
Features
- Head Style
- Flanged Hex/Hex Washer
- Grade
- Grade 8
Certifications & Standards
- Standards
- IFI 111 - SAE J429
