Photographs are representational and may not be size accurate.

OneSource

#10 x 3/4 Inch Black Oxide Hardened Steel #2 Point Pan Head Self-Drilling Tek Screw

Item B25.10.34

Square Drive Pan head self drilling screws have a self driller cutting (TEK) point to pierce through 20 to 14 gauge metals. The heads use a square bit #1 through #3 driver depending on the size of the screw. These screws are used in the exterior elements. Square Drive screws are preferred by some over traditional Phillips Drives because the Square Drive allows for a higher torque installation reduces cam out and reduces screw stripping when compared to Phillips.

Regular price $0.40
Sale price $0.40 Regular price
/ Each

Delivering to

Estimated delivery: 3–7 business days

Order by 2pm CT

Please note that this product is sold in multiples of 1

Photographs are representational and may not be size accurate.

Key Specifications

Diameter #10
Length 3/4 Inch
Head Style Pan
Drive Type Square Socket
Material Hardened Steel
Finish Black Oxide
See all specifications

Description

Square Drive Pan head self drilling screws have a self driller cutting (TEK) point to pierce through 20 to 14 gauge metals. The heads use a square bit #1 through #3 driver depending on the size of the screw. These screws are used in the exterior elements. Square Drive screws are preferred by some over traditional Phillips Drives because the Square Drive allows for a higher torque installation reduces cam out and reduces screw stripping when compared to Phillips.

  • Item: Self-Drilling TEK Screw

Specifications

General

Finish
Black Oxide
Material
Hardened Steel
Measurement System
Inch
Origin
Imported

Dimensions

Diameter
#10
Length
3/4 Inch
Head Diameter
0.357 – 0.373 Inch
Head Height
0.099 – 0.110 Inch
Drive Size
#2
Recess Penetration Gagging Depth
0.089 – 0.113 Inch
Recess Diameter
0.192 Inch

Features

Drive Type
Square Socket
Head Style
Pan
Point Type
3.2 mm

Certifications & Standards

Standards
ASME/ANSI B18.6.4 - SAE J78 - SAE J933
