OneSource
14 Gauge 7/8 Inch X 1-3/8 Inch Astm F844 Clear Zinc Carbon Steel Narrow Rim Machine Bushing
Item E96.14.05
Machine bushings are made of rugged carbon steel for maximum corrosion resistance
Couldn't load pickup availability
Free Shipping On All Orders Over $15
We Stand Behind Our Products
with our 100% quality assurance guarantee.
Quality Assurance Guarantee
OneSource warrants that products delivered by OneSource to customers will be free from defects in material or workmanship under normal use for a period of ninety (90) days from the date of delivery. It is the responsibility of the customer to return defective products within the warranty period. If OneSource determines that the products returned for warranty refund are not defective within the terms of the warranty, the purchaser shall be responsible for all handling and transportation costs.
If an item is returned as defective and it is determined that the product is not, a restocking fee may be charged. Refunds will be issued in the form of an account credit or back to the original payment method.
Photographs are representational and may not be size accurate.
Key Specifications
| Finish | Zinc |
| Material | Carbon Steel |
| Measurement | Inch |
| Retainer Type | Narrow Machine Bushing |
Description
Description
Finish: Zinc
- Hardness RC 30 max.
- Machine bushings are made of rugged carbon steel for maximum corrosion resistance
- Installed axially these round shims are used to take up slack on shafts
- Typical applications include industrial and farm machinery electronic equipment and power transmission assemblies
- Industry Standard: ASTM F844
- Inside Diameter: 7/8 Inch
- Inside Diameter Maximum: 0.900 Inch
- Inside Diameter Minimum: 0.885 Inch
- Item: Machine Bushing
- Material: Carbon Steel
- Measurement: Inch
- Origin: Imported
- Outside Diameter: 1-3/8 Inch
- Outside Diameter Maximum: 1.385 Inch
- Outside Diameter Minimum: 1.368 Inch
- Specification: ASTM F844
- Thickness: 14 Gauge
- Thickness Maximum: 0.082 Inch
- Thickness Minimum: 0.068 Inch
- Type: Narrow Rim
