OneSource

#14 x 1-1/2 Inch Zinc Plated Low Carbon Steel Pan Head Type-A Self-Tapping Sheet Metal Screw

Item B15.63.38

Pan head design is slightly rounded with minimal vertical sides. Square drive is designed to reduce the risk of stripping and allow single-handed installation. Additionally reduces the ability to tamper with the fastener once installed.

Regular price $0.31
Sale price $0.31 Regular price
/ Each

Delivering to

Estimated delivery: 3–7 business days

Order by 2pm CT

Please note that this product is sold in multiples of 1

Photographs are representational and may not be size accurate.

Key Specifications

Diameter #14
Length 1-1/2 Inch
Head Style Pan
Drive Type Phillips
Finish Zinc
Point Type Type A
See all specifications

Description

Pan head design is slightly rounded with minimal vertical sides. Square drive is designed to reduce the risk of stripping and allow single-handed installation. Additionally reduces the ability to tamper with the fastener once installed.

  • Can be substituted in most applications for round truss or binding heads
  • Always use a driver bit of the proper size which is in good condition
  • Item: Self-Tapping Sheet Metal Screw

Specifications

General

Finish
Zinc
Measurement System
Inch
Origin
Imported
Material
Low Carbon Steel

Dimensions

Diameter
#14
Length
1-1/2 Inch
Threads Per Inch
10
Head Diameter
0.457 – 0.476 Inch
Head Height
0.126 – 0.139 Inch
Drive Size
#3
Recess Penetration Gagging Depth
0.118 – 0.144 Inch
Recess Diameter
0.274 Inch

Features

Drive Type
Phillips
Head Style
Pan
Point Type
Type A
Phillips Drive
Most recommended drive type Provides good control in driving

Certifications & Standards

Standards
ASME/ANSI B18.6.4 - SAE J78 - SAE J933
