OneSource

3/4-16 x 2 Inch Fine Black Phosphate & Oil Grade 8 Hex Flange Head Flange Bolt

Item C60.034.2

Specification: IFI 111 1970

Regular price $10.30
Sale price $10.30 Regular price
/ Each

Delivering to

Estimated delivery: 3–7 business days

Order by 2pm CT

Please note that this product is sold in multiples of 1

Photographs are representational and may not be size accurate.

Key Specifications

Diameter 3/4 Inch
Length 2 Inch
Thread Type Fine
Head Style Flanged Hex/Hex Washer
See all specifications

Description

Specification: IFI 111 1970

  • Item: Flange Bolt

Specifications

General

Measurement System
Inch
Type
Partial Threaded
Material
Medium Carbon Steel
Finish
Black Phosphate
Origin
Imported

Dimensions

Diameter
3/4 Inch
Length
2 Inch
Thread Type
Fine
Threads Per Inch
16
Thread Length
1-3/4 Inch
Head Height
0.730 Inch
Width Across Corner
1.234 – 1.299 Inch
Body Diameter
0.741 – 0.750 Inch
Hex Height
0.510 Inch
Flange Diameter
1.590 Inch
Flange Thickness
0.110 Inch

Features

Head Style
Flanged Hex/Hex Washer
Grade
Grade 8

Certifications & Standards

Standards
IFI 111 - SAE J429
