OneSource

5/8-18 x 2-3/4 Inch Fine Black Phosphate & Oil Grade 8 Hex Flange Head Flange Bolt

Item C60.058.234

Specification: IFI 111 1970

Regular price $10.02
Sale price $10.02 Regular price
/ Each

Delivering to

Estimated delivery: 3–7 business days

Order by 2pm CT

Please note that this product is sold in multiples of 1

Photographs are representational and may not be size accurate.

Key Specifications

Diameter 5/8 Inch
Length 2-3/4 Inch
Thread Type Fine
Head Style Flanged Hex/Hex Washer
See all specifications

Description

Specification: IFI 111 1970

  • Item: Flange Bolt

Specifications

General

Measurement System
Inch
Type
Partial Threaded
Material
Medium Carbon Steel
Finish
Black Phosphate
Origin
Imported

Dimensions

Diameter
5/8 Inch
Length
2-3/4 Inch
Thread Type
Fine
Threads Per Inch
18
Thread Length
1-1/2 Inch
Head Height
0.620 Inch
Width Across Corner
1.034 – 1.083 Inch
Body Diameter
0.617 – 0.625 Inch
Hex Height
0.420 Inch
Flange Diameter
1.330 Inch
Flange Thickness
0.100 Inch

Features

Head Style
Flanged Hex/Hex Washer
Grade
Grade 8

Certifications & Standards

Standards
IFI 111 - SAE J429
