Description
Description
Square Drive Pan head self drilling screws have a self driller cutting (TEK) point to pierce through 20 to 14 gauge metals. The heads use a square bit #1 through #3 driver depending on the size of the screw. These screws are used in the exterior elements. Square Drive screws are preferred by some over traditional Phillips Drives because the Square Drive allows for a higher torque installation reduces cam out and reduces screw stripping when compared to Phillips.
- SAE J78Diameter: #8
- Item: Self-Drilling TEK Screw
Specifications
General
- Finish
- Black Oxide
- Material
- Hardened Steel
- Measurement System
- Inch
- Plating
- Black Oxide
Dimensions
- Diameter
- #8
- Length
- 1/2 Inch
- Threads Per Inch
- 18
- Head Diameter
- 0.306 – 0.322 Inch
- Head Height
- 0.105 – 0.115 Inch
- Drive Size
- #2
- Recess Diameter
- 0.175 Inch
Features
- Drive Type
- Square Socket
- Head Style
- Pan
- Point Type
- #3
Certifications & Standards
- Standards
- SAE J78 - ASME/ANSI B18.6.4
Miscellaneous
- Recess Penetration Gaging Depth
- 0.071 – 0.097 Inch
