Hydraulic 3/4 Inch Id X 1.20 Inch Od Extreme Pressure Hose - Sold Per Foot
Item J97.019.12.1
CS-Flex5 Hydraulic Hose is a four-wire braided hose with an extremely diverse range of uses designed for hydraulic Industrial and Agricultural system service with petroleum and water based fluids. Meets or exceeds 100R13/ISO 18752 specs. Higher Pressure applications and has a Reduced Bend Radius
Delivering to
Estimated delivery: 3–7 business days
Order by 2pm CT
Couldn't load pickup availability
-
Free Shipping for All Orders Above $15
Receive free standard ground shipping on single orders totaling $15 or more, after discounts are applied and before taxes.
This offer is only valid in the continental United States.
Excludes expedited shipping methods and orders shipped outside the continental U.S.
-
Quality Assurance Guarantee
OneSource warrants that products delivered by OneSource to customers will be free from defects in material or workmanship under normal use for a period of thirty (30) days from the date of delivery.
It is the responsibility of the customer to return defective products within the warranty period. If OneSource determines that the products returned for warranty refund are not defective within the terms of the warranty, the purchaser shall be responsible for all handling and transportation costs.
If an item is returned as defective and it is determined that the product is not, a restocking fee may be charged.
Refunds will be issued in the form of an account credit or back to the original payment method.
-
Expert Customer Support
Our experts can help. Our experienced sales and support professionals are dedicated to helping you find the right parts for your projects.
Photographs are representational and may not be size accurate.
Key Specifications
| Diameter | 1/4 Inch |
| Material | Rubber |
| Tube Size | 1/4 Inch |
| Color | Green |
Description
Description
CS-Flex5 Hydraulic Hose is a four-wire braided hose with an extremely diverse range of uses designed for hydraulic Industrial and Agricultural system service with petroleum and water based fluids. Meets or exceeds 100R13/ISO 18752 specs. Higher Pressure applications and has a Reduced Bend Radius
- Inner Tube: Synthetic rubber
- Reinforcement: 4 High Tensile Steel Braids
- Cover: Abrasion and Flame Resistant
- Temp. Range: Petroleum-based Hydraulic Fluids -40 C to +121 C (-40 F to +250 F)
- Hose Ends: 4S GW 4GC 4SH 6GC
- Typical Application: Hydraulic system service with petroleum and water-based fluids for general industrial Agricultural service
- MSHA Approved - Exceeds 100R13 and ISO 18752 specs
Specifications
General
- Color
- Green
- Material
- Rubber
Dimensions
- Tube Size
- 1/4 Inch
- Diameter
- 1/4 Inch
