OneSource
M10 x 1.5 x 140 Mm Coarse Class 8.8 Yellow Zinc Steel Hex Head Cap Screw
Item A53.010.140
Couldn't load pickup availability
Free Shipping On All Orders Over $15
We Stand Behind Our Products
with our 100% quality assurance guarantee.
Quality Assurance Guarantee
OneSource warrants that products delivered by OneSource to customers will be free from defects in material or workmanship under normal use for a period of ninety (90) days from the date of delivery. It is the responsibility of the customer to return defective products within the warranty period. If OneSource determines that the products returned for warranty refund are not defective within the terms of the warranty, the purchaser shall be responsible for all handling and transportation costs.
If an item is returned as defective and it is determined that the product is not, a restocking fee may be charged. Refunds will be issued in the form of an account credit or back to the original payment method.
Description
Description
Origin: Imported Diameter: M10 Diameter Thread Size: M10 x 1.50 Finish: Yellow Zinc Grade: Class 8.8 Head Height Max: 6.4 mm Height Head Style: 0.019 Inch Head Type: Hex Item: Cap Screw Length: 140 mm Material: Steel Measurement: Metric Origin: Imported Proof Load: 84100 psi Specification: DIN 931 Tensile Strength : 116000 psi Thread Length: 32 mm Thread Type: Coarse Type: Partial Threaded Width Across Corner: 18.9 mm
- Origin: Imported
- Diameter Thread Size: M10 x 1.50
- Finish: Yellow Zinc
- Grade: Class 8.8
- Head Height Max: 6.4 mm Height
- Head Style: 0.019 Inch
- Head Type: Hex
- Item: Cap Screw
- Length: 140 mm
- Material: Steel
- Measurement: Metric
- Origin: Imported
- Proof Load: 84100 psi
- Specification: DIN 931
- Tensile Strength : 116000 psi
- Thread Length: 32 mm
- Thread Type: Coarse
- Type: Partial Threaded
- Width Across Corner: 18.9 mm
Photographs are representational and may not be size accurate.
Key Specifications
| Diameter | M10 |
| Finish | Yellow Zinc |
| Head Style | Hex |
| Length | 140 mm |
| Measurement | Metric |
| Thread Type | Coarse |
