Description
Description
Pan head design is slightly rounded with minimal vertical sides. Square drive is designed to reduce the risk of stripping and allow single-handed installation. Additionally reduces the ability to tamper with the fastener once installed.
- Item: 0.032 Inch
Specifications
General
- Finish
- Plain
- Measurement System
- Metric
- Type
- Full Threaded
- Material
- Stainless Steel 18-8 (A2)
- Origin
- Imported
Dimensions
- Diameter
- M6
- Length
- 20 mm
- Thread Type
- Coarse
- Thread Length
- 20 mm
- Head Diameter
- 11.57 – 12 mm
- Head Height
- 4.45 – 4.75 mm
- Recess Penetration Gagging Depth
- 3.03 – 3.53 mm
- Recess Diameter
- 3 mm
Features
- Drive Type
- Phillips
- Head Style
- Pan
- Tensile Strength
- 72,500 psi
- Yield Strength
- 30,450 Psi
Certifications & Standards
- Standards
- DIN 7985
