The Star Alloys 2200DS Dissimilar Steel electrodes are excellent for stud pulling and broken stud and bolt removal. Ideal for any welding position such as flat horizontal vertical up and down and overhead positions.

• Excellent for stud pulling and broken stud and bolt removal
• Special all-position high tensile strength electrode for all steels and dissimilar metals
• Unique “Quick Freeze” coating simplifies vertical down and up welding
• Ideal for poor fit up joints in all positions
• Controlled weld puddle allows for filling holes and joining dissimilar steels
• Welds even dirty and greasy metal Saves prep time
• Use to solve the problem of welding “mystery metals”
• Creates very little smoke compared to other electrodes
• Runs with very low spatter so it’s safer to operate
• Ideal for repairing tools dies spring steel and any dissimilar metal combinations except for aluminum and copper alloys
• Welding Positions: flat horizontal vertical up and down and overhead
• Recommended Current: DC reverse (+) or AC
• Recommended Amperage Settings (min/max): 5/64” (35/55); 3/32” (35/70); 1/8” (60/110); 5/32” (75/140) • Tensile Strength as Welded: 128 000 psi
• Tensile Strength Work Hardened: 186 000 psi
• Yield Strength: 90 000 psi
• Hardness: Rockwell B97; Brinell 320
• Elongation: 32%
